Product Overview
Built to withstand the corrosive conditions encountered within waste water environments, Multilog 2 WW is specifically designed to be compatible with various third-party sensors, including RavenEye, MicroFlow-i, dBi and VEGAPULS.
Including four sensor connections and delivering up to 8 logging channels, Multilog 2 WW is highly versatile and is suitable for a wide array of applications, including depth, flow, and quality data logging, battery telemetry for third-party radar depth and velocity sensors, and Modbus cellular
Explicitly designed for non-ATEX applications, Multilog 2 WW is housed in a drop-tested non-metallic casing and has non-metallic connectors to prevent corrosion in harsh environments.
A highly compatible, self-powered data logger that benefits from our advanced modem for dependable connectivity, Multilog 2 WW is the ideal solution for non-ATEX environmental and wastewater monitoring.
Key Features
- Cellular: LTE-M-based cellular communication as standard with fallback 2G capability
- Serial and analog input option: for connection to SonicSens 3 ultrasonic level sensor, internal or external pressure transducers, active/passive 4-20mA, voltage, digital pulses, Modbus, SDI12
- 4 channel logging: up to 8 channels
- Alarm: highly configurable alarms
- Robust: Drop-tested plastic housing and connectors to prevent corrosion in harsh environments
- Statistical logging: max, min, average and standard dev recording available
- State Event recording: for precise recording of events like float trigger or rain gauge
- Bulgin antennas: support improved signal strength – contact HWM for details of our wide-ranging options
- Local data download: 6 pin military plug connected to laptop or desktop PC
- Fully waterproof: the IP68 rating has been tested at 10m depth over a 24 hour period
- Control outputs: replicated pulse inputs or trigger on alarm, allows operation of third-party sensors, e.g. water samplers
- Long-term monitoring: 5 year battery life
- External battery option: external battery input to support accelerated dial-in or powering of third party sensors
- Remote upgrades: firmware and programming changes made remotely for efficiency and cost-effectiveness
- Secondary channel: enables additional fast logging down to 25Hz
